Purchase AMC7823, In-stock AMC7823 From SeekIC.
Package Cooled:06+ D/C:QFN-40
Part Number: AMC7823
Package Cooled: 06+
D/C: QFN-40
Description: The AMC7823 is a complete analog monitoring and control circuit that includes an 8-channel, 12-bit ana...
- Table of contents:
AMC7823
-
Suppliers
DataSheet
General Description
AMC7823 General Description
The AMC7823 is a complete analog monitoring and control circuit that includes an 8-channel, 12-bit analog-to-digital converter (ADC), eight 12-bit digitalto-analog converters (DACs), four analog input out-of-range alarms, and six GPIOs to monitor analog signals and control external devices. Also, the AMC7823 has an internal sensor to monitor chip temperature, and a precision current source to drive remote thermistors, or RTDs, to monitor remote temperatures.
The AMC7823 has an internal programmable reference (+2.5 V or +1.25 V), and an SPI serial interface. An external reference can be used as well. Typical power dissipation is 100 mW. The analog input range is 0 V to +5 V, and the analog output range is 0 V to +2.5 V or 0 V to +5 V. The AMC7823 is ideal for multichannel applications where low power and small size are critical. The AMC7823 is available in a 40-lead QFN package and is fully specified over the 40°C to +85°C temperature range.
AMC7823 Maximum Ratings
| AMC7823 | UNIT | ||
| AVDD, DVDD, BVDD to GND | 0.3 to +6 | V | |
| Digital input voltage to GND | 0.3 to BVDD + 0.3 | V | |
| Analog input voltage to GND | 0.3 to AVDD + 0.3 | V | |
| Input current, continuous | ±20 | mA | |
| Input current, momentary | ±100 | mA | |
| Operating temperature range | 40 to +105 | °C | |
| Storage temperature range | 65 to +150 | °C | |
| Junction temperature range (TJ max) | +150 | °C | |
| Power dissipation | (TJ max TA) /
JA |
W | |
| Thermal impedance,
JC |
15 | °C/W | |
| Thermal impedance,
JA |
60 | °C/W | |
| Lead temperature (soldering) | Vapor phase (60s) | +215 | °C |
| Lead temperature (soldering) | Infrared (15s) | +220 | °C |
(1) Stresses above those listed under absolute maximum ratings may cause permanent damage to the device. Exposure to absolute maximum conditions for extended periods may affect device reliability.
AMC7823 Features
` 12-Bit ADC (200 kSPS)
Eight Analog Inputs
Input Range 0 to 2 ´ VREF
` Programmable VREF, 1.25 V or 2.5 V
` Eight 12-Bit DACs (2-ms Settling Time)
` Four Analog Input Out-of-Range Alarms
` Six General-Purpose Digital I/O
` Internal Bandgap Reference
` On-Chip Temperature Sensor
` Precision Current Source
` SPI™ Interface, 3-V or 5-V Logic Compatible
` Single 3-V to 5-V Supply
` Power-Down Mode/Low Power
` Small Package (QFN-40, 6 * 6 mm)
Eight Analog Inputs
Input Range 0 to 2 ´ VREF
` Programmable VREF, 1.25 V or 2.5 V
` Eight 12-Bit DACs (2-ms Settling Time)
` Four Analog Input Out-of-Range Alarms
` Six General-Purpose Digital I/O
` Internal Bandgap Reference
` On-Chip Temperature Sensor
` Precision Current Source
` SPI™ Interface, 3-V or 5-V Logic Compatible
` Single 3-V to 5-V Supply
` Power-Down Mode/Low Power
` Small Package (QFN-40, 6 * 6 mm)
AMC7823 Typical Application
· Communications Equipment
· Optical Networks
· Automatic Test Equipment
· Industrial Control and Monitor
· Medical Equipment
· Optical Networks
· Automatic Test Equipment
· Industrial Control and Monitor
· Medical Equipment
AMC7823
PDF/DataSheet Download
- Datasheet: AMC7823
- File Size: 1821191 KB
- Manufacturer: TI [Texas Instruments]
- Click here to Download
