AN3479FBP
-
Suppliers
DataSheet
General Description
AN3479FBP Maximum Ratings
| Parameter | Symbol | Ratings | Unit |
| Supply voltage | VCC | 5.5 | V |
| Supply current | ICC | 222 | mA |
| Power dissipation *2 | PD | 958 | mW |
| Operating ambient temperature *1 | Topr | -20 ~ +70 | |
| Storage temperature *1 | Tstg | -55 ~ +150 |
AN3479FBP Features
· Compatible with I2C-bus
· Totally free of adjustments
· Low-frequency comb system
· An improved chroma S/N ratio ensured by built-in CNR and CPC(chroma phase compensator) circuits
· Compatible with SQPB
· Totally free of adjustments
· Low-frequency comb system
· An improved chroma S/N ratio ensured by built-in CNR and CPC(chroma phase compensator) circuits
· Compatible with SQPB
AN3479FBP Typical Application
· VCR(NTSC)
AN3479FBP
PDF/DataSheet Download
- Datasheet: AN3479FBP
- File Size: 144959 KB
- Manufacturer: PANASONIC [Panasonic Semiconductor]
- Click here to Download
