ANX9030

The ANX9030 is a highperformance, High Definition Media Interface (HDMI) transmitter chip with an advanced feature set offered only by Analogix Semiconductor.

The ANX9030 is pincompatible with the SiI9030 yet offers additional features and functionality and lower power operation. It includes HDCP 1.2 (HighBandwidth Digital Content Protection) circuitry with internal memory to store a unique HDCP device key.

The device directly interfaces to the HDMI output connector of an HDMIenabled digital video source, such as a digital settop box, DVD player, or integrated Audio/Video receiver. It also includes other HDMI connector functions such as the I2C interface for the DDC (Display Data Channel) and the Hot Plug Detection input.

The ANX9030 accepts digital video and audio in many commonly used data formats, sample rates, and bit resolutions. Video, audio, auxiliary, and control data is packetized according to HDMI standards, making the ANX9030 fully compatible with HDMI receivers such as the ANX9011 and ANX9021.

The ANX9030 is offered in an 80lead TQFP package
