Part Number: AO4726
Description: SRFET TM The AO4726/L uses advanced trench technology with a monolithically integrated Schottky diode ...
- Table of contents:
AO4726
-
Suppliers
DataSheet
General Description
AO4726 General Description
SRFET TM The AO4726/L uses advanced trench technology with a monolithically integrated Schottky diode to provide excellent R DS(ON) and low gate charge.
This device is suitable for use as a low side FET in SMPS, load switching and general purpose applications. AO4726 and AO4726L are electrically identical.
-RoHS Compliant
-AO4726L is Halogen Free
AO4726 Maximum Ratings
| Parameter | Symbol | Maximum | Units | |
| Gate-Source Voltage Drain-Source Voltage |
VDS VGS |
30 ±12 |
V | |
| Continuous Drain Current AF |
TA=25 | IDSM | 18 | A |
| TA=70 | 14 | |||
| Avalanche Current B Repetitive avalanche energy L=0.3mH B Pulsed Drain Current B |
IDM IAR EAR |
80 42 265 |
A mJ | |
| Power Dissipation | TA=25 | PDSM | 3.1 | W |
| TA=70 | 2.0 | |||
| Junction and Storage Temperature Range | TJ, TSTG | -55 to 150 | ||
AO4726 Features
VDS (V) = 30V
ID =18A (VGS = 10V)
RDS(ON) < 6mΩ (VGS = 10V)
RDS(ON) < 7mΩ (VGS = 4.5V)
ID =18A (VGS = 10V)
RDS(ON) < 6mΩ (VGS = 10V)
RDS(ON) < 7mΩ (VGS = 4.5V)
AO4726 Connection Diagram
