AP033

Tip Style : Multi Point
Equipment Type : Active Probe


Features:

• 3-Terminal and Fixed 3.3V
• 1.4V Maximum Dropout at Full Load Current.
• Fast Transient Response.
• Built-in Thermal Shutdown.
• Output Current Limiting.


Application

• PC peripheral
• Communication


Specifications

Symbol	Parameter	Rating	Unit
Vin	DC Supply Voltage	-0.3 to 14	V
PD	Power Dissipation	Internally Limited
TST	Storage Temperature	-65 to +150	oC
TOP	Operating Junction Temperature Range	0 to +150	oC

Description

AP033 is a low dropout positive fixed-mode regulator with minimum of 1.5A output current capability. The product is specifically designed to provide well-regulated supply for low voltage IC
applications such as high-speed bus termination and low current 3.3V logic supply. AP033 is guaranteed to have <1.4V dropout at full load current making it ideal to provide well regulatedoutputs of 3.3V with 4.7V to 12V input supply by different output voltage.
