Purchase AQY214EHAX, In-stock AQY214EHAX From SeekIC.
MFG:NAIS Package Cooled:SOP D/C:00+
- Table of contents:
AQY214EHAX
-
Suppliers
DataSheet
General Description
AQY214EHAX Maximum Ratings
| Item |
Symbol |
AQY210EH (A) |
AQY214EH (A) |
Remarks | |
| Input | LED forward current |
IF |
50 mA |
||
| LED reverse voltage |
VR |
3 V |
|||
| Peak forward current |
IFP |
1 A |
f = 100 Hz, Duty factor = 0.1% | ||
| Power dissipation |
Pin |
75 mW |
|||
| Output | Load voltage (peak AC) |
VL |
350 V |
400 V |
Effective Vrms |
| Continuous load current |
IL |
0.13 A |
0.12 A |
||
| Peak load current |
Ipeak |
0.4 A |
0.3 A |
100 ms (1 shot), VL = DC | |
| Power dissipation |
Pout |
500mW |
|||
| Total power dissipation |
PT |
550mW |
|||
| I/O isolation voltage |
Viso |
5,000 V AC |
|||
| Temperature limits | Operating |
Topr |
40°C to +85°C |
Non-condensing at low temperatures | |
| Storage |
Tstg |
40°C to +100°C |
|||
AQY214EHAX Features
1. Reinforced insulation 5,000 V type More than 0.4 mm internal insulation distance between inputs and outputs. Conforms to EN41003, EN60950 (reinforced insulation).
2. Compact 4-pin DIP size The device comes in a compact (W)6.4*(L)4.78*(H)3.2mm (W).252*(L).188*(H).126inch, 4-pin DIP size.
3. Controls low-level analog signals PhotoMOS relays feature extremely low closed-circuit offset voltage to enable control of low-level analog signals without distortion.
4. High sensitivity, low ON resistance Can control a maximum 0.13 A load current with a 5 mA input current. Low ON resistance of 25 (AQY210EH). Stable operation because there are no metallic contact parts.
5. Low-level off state leakage current The SSR has an off state leakage current of several milliamperes, whereas the PhotoMOS relay has only 100 pA even with the rated load voltage of 350 V (AQY210EH).
2. Compact 4-pin DIP size The device comes in a compact (W)6.4*(L)4.78*(H)3.2mm (W).252*(L).188*(H).126inch, 4-pin DIP size.
3. Controls low-level analog signals PhotoMOS relays feature extremely low closed-circuit offset voltage to enable control of low-level analog signals without distortion.
4. High sensitivity, low ON resistance Can control a maximum 0.13 A load current with a 5 mA input current. Low ON resistance of 25 (AQY210EH). Stable operation because there are no metallic contact parts.
5. Low-level off state leakage current The SSR has an off state leakage current of several milliamperes, whereas the PhotoMOS relay has only 100 pA even with the rated load voltage of 350 V (AQY210EH).
AQY214EHAX Typical Application
• Modem
• Telephone equipment
• Security equipment
• Sensors
• Telephone equipment
• Security equipment
• Sensors
