Part Number: AR480











Urgent Purchase

AR480 Maximum Ratings

VRRM6000[V]IF(AV)sine wave 50 Hz Th=55C873[A]IF(AV)sine wave 50 Hz Th=85C-[A]IFSMsine wave 10 ms Vr<10V8.0[kA]I²tTj max320[A²•s•10³]IRRMTj max70[mA]Tj max150[°C]VF(TO)Tj max1.00[V]rFTj max0.125[mΩ]Rth(j-h)Double side RthDC = Rth 180 sin37[°C/kW]Rth(j-h)Double side Rth 120 sin-[°C/kW]Weight300[g]Fmin/max suggested range11.8/13.2[kN]OUTLINEC0

AR480 datasheet

AR4000-03
PDF/DataSheet Download
