MFG:AT Package Cooled:PLCC
MFG: AT
Package Cooled: PLCC
Description: The AT27LV010A is a high performance, low power, low voltage 1,048,576 bit onetime programmable read o...
The AT27LV010A is a high performance, low power, low voltage 1,048,576 bit onetime programmable read only memory (OTP EPROM) organized as 128K by 8 bits. It requires only one supply in the range of 3.0V to 3.6V in normal read mode operation, making it ideal for fast, portable systems using battery power.
Atmel's innovative design techniques provide fast speeds that rival 5V parts while keeping the low power consumption of a 3.3V supply. At VCC = 3.0V, any byte can be accessed in less than 90 ns. With a typical power dissipation of only 18 mW at 5 MHz and VCC = 3.3V, the AT27LV010A consumes less than one fifth the power of a standard 5V EPROM. Standby mode supply current is typically less than 1 A at 3.3V.
Temperature Under Bias ............... -40 to +85
Storage Temperature...................-65 to +125
Voltage on Any Pin with
Respect to Ground.....................-2.0V to +7.0V (1)
Voltage on A9 with
Respect to Ground ................ -2.0V to +14.0V (1)
VPP Supply Voltage with
Respect to Ground.................. -2.0V to +14.0V (1)
*NOTICE: Stresses beyond those listed under "Absolute Maximum Ratings" may cause permanent damage to the device. This is a stress rating only and functional operation of the device at these or any other conditions beyond those indicated in the operational sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.
Note: 1. Minimum voltage is -0.6V dc which may undershoot to - 2.0V for pulses of less than 20 ns. Maximum output
pin voltage is VCC + 0.75V dc which may be exceeded if certain precautions are observed (consult application notes) and which may overshoot to +7.0 volts for pulses of less than 20 ns.
AT27LV010A
PDF/DataSheet Download
