Supply Current
:
Memory Type
: EEPROM
Number of Product Terms per Macro
: 40
Maximum Operating Temperature
: + 85 C
Minimum Operating Temperature
: - 40 C
Number of Macrocells
: 128
Maximum Operating Frequency
: 125 MHz
Delay Time
: 10 ns
Operating Supply Voltage
: 5 V
Number of Programmable I/Os
: 80
Package / Case
: TQFP-100
DescriptionThe ATF1508AS-10AU100 is one member of the ATF1508AS family which is designed as the high-performance, high-density complex programmable logic device (CPLD). Also this device has up to 96 bi-directional I/O pins and four dedicated input pins, depending on the type of device package selected; and each of the 128 macrocells generates a buried feedback that goes to the global bus.
Features of the ATF1508AS-10AU100 are:(1)5 Product Terms per Macrocell, Expandable up to 40 per Macrocell ; (2)84, 100, 160 Pins ; (3)7.5 ns Maximum Pin-to-pin Delay ; (4)D/T/Latch Configured Flip-flops ; (5)Global and Individual Register Control Signals ; (6)Maximum Logic Utilization by Burying a Register within a COM Output ; (7)Available in Commercial and Industrial Temperature Ranges ; (8)Available in 84-lead PLCC, 100-lead PQFP, 100-lead TQFP and 160-lead PQFP Packages ; (9)JTAG Boundary-scan Testing to IEEE Std. 1149.1-1990 and 1149.1a-1993 Supported ; (10)Fast In-System Programmability (ISP) via JTAG ; (11)PCI-compliant; (12)3.3 or 5.0V I/O Pins; (13)Security Fuse Feature; (14)Green (Pb/Halide-free/RoHS Compliant) Package Options.
The absolute maximum ratings of the ATF1508AS-10AU100 can be summarized as:(1)Supply Voltage:4.75 to 5.25 V;(2)Input High Voltage:2.0 to VCC+0.5 V;(3)Input Low Voltage:-0.5 to 0.8 V;(4)Input High Leakage Current:70 A;(5)Input Low Leakage Current:-70 A;(6)Output High Voltage:2.4 V;(7)Output Low Voltage:0.55 V;(8)Input Pin Capacitance:10 pF;(9)CLK Pin Capacitance:12 pF;(10)IDSEL Pin Capacitance:8 pF. If you want to know more information such as the electrical characteristics about the ATF1508AS-10AU100, please download the datasheet in www.seekic.com or www.chinaicmart.com .
Parameters: | Technical/Catalog Information | ATF1508AS-10AU100 |
| Vendor | Atmel |
| Category | Integrated Circuits (ICs) |
| Programmable Type | In System Programmable (min 10K program/erase cycles) |
| Number of Macrocells | 128 |
| Number of I /O | 80 |
| Number of Logic Blocks/Elements | - |
| Operating Temperature | -40°C ~ 85°C |
| Package / Case | 100-TQFP |
| Features | - |
| Voltage | 5V |
| Memory Type | EEPROM |
| Delay Time tpd(1) Max | 10.0nS |
| Packaging | Tray |
| Lead Free Status | Lead Free |
| RoHS Status | RoHS Compliant |
| Other Names | ATF1508AS 10AU100
