General Description
ATSAM2193 General Description
The ATSAM2193 provides a single-chip, low-cost MIDI sound system. Equipped with a serial and a parallel MIDI input, it provides state-of-the-art sound synthesis using a full GM sound set together with a range of compatible effects. Its low power consump-tion makes it ideal for all battery-powered applications such as portable Karaoke or any other device using MIDI synthesis.
The ATSAM2193-G has the same functionality as the ATSAM2193 but is presented in a TFBGA44 package.
ATSAM2193 Maximum Ratings
Ambient Temperature (Power applied) .......... -40°C to +85°C
Storage Temperature.................................... -65°C to +150°C
Voltage on Input Pins............................... -0.5V to VC3 + 0.3V
(except X1 and PDWN)
Voltage on X1 and PDWN Pins.................. -0.5V to VC2 + 0.3V
VC2 Supply Voltage (core).....................................-0.5V to +3V
VC3 Supply Voltage (I/O) ...................................-0.3V to +4.5V
Maximum IOL per I/O pin................................................. 4 mA
Storage Temperature.................................... -65°C to +150°C
Voltage on Input Pins............................... -0.5V to VC3 + 0.3V
(except X1 and PDWN)
Voltage on X1 and PDWN Pins.................. -0.5V to VC2 + 0.3V
VC2 Supply Voltage (core).....................................-0.5V to +3V
VC3 Supply Voltage (I/O) ...................................-0.3V to +4.5V
Maximum IOL per I/O pin................................................. 4 mA
ATSAM2193 Features
• Single-chip All-in-one Design, Only Requires External DAC
MIDI Control Processor, Serial and Parallel Interface
Synthesis, General MIDI Wavetable Implementation
Compatible Effects: Reverb + Chorus
Spatial Effect
4-band Stereo Equalizer
• State-of-the-art Synthesis for Best Quality/Price Products
38-voice Polyphony + Effects
On-chip CleanWave™ Wavetable Data, Firmware, RAM Delay Lines
• Synthesizer Chipset: ATSAM2193/ATSAM2193-G + DAC
• Hardware Programmable DAC Mode
I2S: 16 to 20 bits
Japanese: 16 bits
• Typical Applications
Battery-operated Musical Keyboards
Portable Phones
Karaokes
• TQFP44 (10 mm x 10 mm) Package for ATSAM2193
TFBGA44 (7 mm x 7 mm) Package for ATSAM2193-G
Both Options Provide Small Footprint, Low Pin Count
• Low-power
95 mW Typical Operating, <5 µA Power-down
2.5V and 3.3V Power Supply or Single 2.5V Supply
Built-in Power Switch
MIDI Control Processor, Serial and Parallel Interface
Synthesis, General MIDI Wavetable Implementation
Compatible Effects: Reverb + Chorus
Spatial Effect
4-band Stereo Equalizer
• State-of-the-art Synthesis for Best Quality/Price Products
38-voice Polyphony + Effects
On-chip CleanWave™ Wavetable Data, Firmware, RAM Delay Lines
• Synthesizer Chipset: ATSAM2193/ATSAM2193-G + DAC
• Hardware Programmable DAC Mode
I2S: 16 to 20 bits
Japanese: 16 bits
• Typical Applications
Battery-operated Musical Keyboards
Portable Phones
Karaokes
• TQFP44 (10 mm x 10 mm) Package for ATSAM2193
TFBGA44 (7 mm x 7 mm) Package for ATSAM2193-G
Both Options Provide Small Footprint, Low Pin Count
• Low-power
95 mW Typical Operating, <5 µA Power-down
2.5V and 3.3V Power Supply or Single 2.5V Supply
Built-in Power Switch
