Purchase BA4424N, In-stock BA4424N From SeekIC.
MFG:ROHM Package Cooled:SIP
Part Number: BA4424N
MFG: ROHM
Package Cooled: SIP
Description: The BA4424N is a monolithic IC designed for FM front end use. It consists of an RF amplifier circuit, ...
- Table of contents:
BA4424N
-
Suppliers
DataSheet
General Description
BA4424N General Description
The BA4424N is a monolithic IC designed for FM front end use. It consists of an RF amplifier circuit, mixer circuit, local oscillation circuit, IF buffer amplifier, and a variable capacitor-diode for AFC.
BA4424N Features
1) An RF amplifier, mixer, local oscillator, IF buffer amplifier,
and AFC diode are included on-chip.
2) Reception of VHF terrestrial TV channels is possible.
3) Uses a double balance mixer to improve intermodulation characteristics.
4) Includes a clamp diode in the mixer output.
5) Local oscillation buffer on-chip for improved response to strong input.
6) The output impedance of the IF buffer amplifier is
matched with the ceramic filter impedance at 330W.
7) A resistive load can also be used for the mixer output.
8) Mixer input coupling capacitor included on-chip.
9) Includes a feedback capacitor for the local oscillation circuit.
10) Compact 9-pin SIP package. Pins arranged for
convenient mounting.
and AFC diode are included on-chip.
2) Reception of VHF terrestrial TV channels is possible.
3) Uses a double balance mixer to improve intermodulation characteristics.
4) Includes a clamp diode in the mixer output.
5) Local oscillation buffer on-chip for improved response to strong input.
6) The output impedance of the IF buffer amplifier is
matched with the ceramic filter impedance at 330W.
7) A resistive load can also be used for the mixer output.
8) Mixer input coupling capacitor included on-chip.
9) Includes a feedback capacitor for the local oscillation circuit.
10) Compact 9-pin SIP package. Pins arranged for
convenient mounting.
BA4424N
PDF/DataSheet Download
- Datasheet: BA4424N
- File Size: 111639 KB
- Manufacturer: ROHM [Rohm]
- Click here to Download
