Part Number: BA4425F





Package Cooled: 0

D/C: SOP-8

Description: The BA4425F is a monolithic IC designed for FM front end use. It consists of an RF amplifier circuit, mixer circuit, os...


Urgent Purchase

BA4425F General Description


The BA4425F is a monolithic IC designed for FM front end use. It consists of an RF amplifier circuit, mixer circuit, oscillation circuit, and IF buffer amplifier.

BA4425F Features

1) Uses double balance mixer to improve intermodulation characteristics.
2) Includes a clamp diode in the mixer output.
3) Local oscillation buffer on-chip for improved response to strong input.
4) The output impedance of the IF buffer is matched with the ceramic filter impedance at 330W.
5) Mixer input coupling capacitor included on-chip.
6) Includes a feedback capacitor for the local oscillation circuit.
7) Reception of VHF terrestrial TV channels is possible.
8) Compact SOP 8-pin package.

BA4425F Typical Application

· FM radios
· Radio cassette players
· Home stereos
· Headphone stereos
