Purchase BA5915FP, In-stock BA5915FP From SeekIC.

MFG:ROHM  Package Cooled:SOP-28  D/C:02+

BA5915FP Product Image

BA5 Series Datasheet download

Five Points

Part Number: BA5915FP



MFG: ROHM

Package Cooled: SOP-28

D/C: 02+

Description: The BA5915FP contains a 4-channel BTL driver for CD player motors and actuators and a multi-purpose op...


Urgent Purchase

BA5915FP General Description


The BA5915FP contains a 4-channel BTL driver for CD player motors and actuators and a multi-purpose operational amplifier. Perfect for compact applications with the use of the HSOP 28-pin package.

BA5915FP Features

1) 4-channel BTL driver.
2) Wide dynamic range (3.55V (Typ.) when VCC = 5V and RL = 8W).
3) Internal thermal shutdown circuit.
4) Gain is adjustable with externally connected resistor.
5) Internal multi-purpose operational amplifier.
6) External mute pin enables the muting of the output current for channel 1.
7) Perfect for compact applications with the use of the HSOP 28-pin power package.

BA5915FP Typical Application

CD players, CD-ROM
