Part Number: BH3864F



MFG: ROHM

Package Cooled: SMD



Description: The BH3864F has been developed for use in mini-component stereo systems. Switching is done using a resistor ladder to s...


Urgent Purchase

BH3864F General Description


The BH3864F has been developed for use in mini-component stereo systems. Switching is done using a resistor ladder to suppress DC offset at switching. Two-line serial control is available, and external three-line serial control is also possible. The package is a compact 24-pin SOP.

BH3864F Features

1) Volume, tone, and dynamic bass boost control possible by a serial link to a microprocessor.

2) Left and right channel volume can be controlled indePendently.

3) Resistor-ladder type volume control uses BiCMOS process for low distortion and noise.

4) Dynamic bass and linked ALC are provided on chip.

BH3864F Typical Application

Mini-and micro-component stereo systems, CD radio cassette players and TVs.

BH3864F datasheet

BH3864F
PDF/DataSheet Download
