BKBL-400-1C

PARAMETER (TEST CONDITIONS)	SYMBOL	RATINGS								UNITS
Series Number		KBL00	KBL01	KBL02	KBL04	KBL06	KBL08	KBL10
Maximum DC blocking voltage	VRM	50	100	200	400	600	800	1000	VOLTS
Maximum RMS voltage	VRMS	35	70	140	280	420	560	700
Maximum Peak Recurrent Reverse Voltage	VRRM	50	100	200	400	600	800	1000
Average Forward Rectified Current @ TA = 65	IO	4							AMPS
Peak forward surge current 3 Single 60Hz Half-Sine Wave AMPSSuperimposed on Rated Load (JEDEC Method). TJ = 150	IFSM	200
Maximum Forward Voltage (Per Diode) at 4 Amps DC	VFM	0.95 (Typical < 0.90)							VOLTS
Maximum Average DC Reverse Current@ TA = 25 At Rated DC Blocking Voltage @ TA = 125	IRM	1 50							A
Typical Thermal Resistance Junction to Lead (Note 1)	RJA RJL	19.0 2.4							/W
Minimum Insulation Breakdown Voltage (Circuit to Case)	VISO	2500							VOLTS
Operating and Storage Temperature Range	TJ,TSTG	-55 to +150

NOTES:(1)Bridge  mounted  on  PC  Board  with 0.5 sq.(12mm sq .) copper  pads  and a lead  length
            of 0.375"(9.5mm)
