BLA1011-200

Transistors RF MOSFET Power BULK TNS-MICP

product image

BLA1011-200 Picture
See larger image
SeekIC No. : 00220678 Detail

BLA1011-200: Transistors RF MOSFET Power BULK TNS-MICP

BLA1011-200 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
BLA1011-200
Mfg:
NXP Semiconductors
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/26

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Configuration : Single Transistor Polarity : N-Channel
Frequency : 1.03 GHz to 1.09 GHz Gain : 13 dB
Output Power : 200 W Drain-Source Breakdown Voltage : 75 V
Gate-Source Breakdown Voltage : +/- 22 V Maximum Operating Temperature : + 150 C
Package / Case : SOT-538A Packaging : Reel

Description

Continuous Drain Current :
Configuration : Single
Transistor Polarity : N-Channel
Maximum Operating Temperature : + 150 C
Packaging : Reel
Gain : 13 dB
Output Power : 200 W
Frequency : 1.03 GHz to 1.09 GHz
Package / Case : SOT-538A
Drain-Source Breakdown Voltage : 75 V
Gate-Source Breakdown Voltage : +/- 22 V


Features:

• High power gain
• Easy power control
• Excellent ruggedness
• Source on mounting base eliminates DC isolators, reducing common mode inductance.


Application

• Avionics transmitter applications in the 1030 to 1090 MHz frequency range.


Specifications

SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT
VDS drain-source voltage   − 65 V
VGS gate-source voltage   − ±15 V
Ptot total power dissipation Th 25 °C;Tp =50 µs; =2% − tbd A
Tstg storage temperature   −65 +150 °C
Tj junction temperature   − 200 °C



Description

Silicon N-channel enhancement mode lateral D-MOS transistor BLA1011-200 encapsulated in a 2-lead SOT502A flange package with a ceramic cap. The common source is connected to the mounting flange.
