MFG:N/A Package Cooled:. D/C:08+
MFG: N/A
Package Cooled: .
D/C: 08+
Description: NPN silicon planar epitaxial transistors primarily intended for common emitter class-AB operation. The transistors have...
| SYMBOL | PARAMETER | CONDITIONS | MIN. | MAX. | UNIT |
| VCBO | collector-base voltage | open emitter | 70 | V | |
| VCES | collector-emitter voltage | open base | 30 | V | |
| VEBO | emitter-base voltage | open collector | 3 | V | |
| IC | collector current | DC or average value | 15 | A | |
| ICM | collector current | peak value f > 1 MHz | 15 | A | |
| Ptot | total power dissipation | f > 1 MHz;Ts = 103 °C (note 1) |
250 | W | |
| Tstg | storage temperature | -65 | +150 | ||
| Tj | operating junction temperature | 200 |
BLV958
