BR24L32-FV
-
Suppliers
DataSheet
General Description
BR24L32-FV Features
* 32k bit serial EEPROM organized as 4k * 8bit (BR24L32)
64k bit serial EEPROM organized as 8k * 8bit (BR24L64)
* 2 wire bus serial interface (2 byte Address)
* Low operating voltage range (2V operating)
Read : 1.8~5.5V
Write : 1.8~5.5V
* Low current consumption
Active : 3mA MAX
Standby : 2A MAX
* Clock frequency : 100kHz MAX (1.8~5.5V)
400kHz MAX (2.5~5.5V)
* Write cycle time : 5ms MAX
* Address auto-increment function during read operation
* Automatic erase-before-write function during write operation
* Page write function : 32byte
* Inadvertent write protection function
Inadvertent write protection at low voltage (Vcc Lock-out function)
WP (Write Protect) function
* Schmitt trigger circuit and noise filter are built into SCL and SDA pins
* 1,000,000 write cycle typical
* 40 years data retention
* Operating temperature range : -40~85
64k bit serial EEPROM organized as 8k * 8bit (BR24L64)
* 2 wire bus serial interface (2 byte Address)
* Low operating voltage range (2V operating)
Read : 1.8~5.5V
Write : 1.8~5.5V
* Low current consumption
Active : 3mA MAX
Standby : 2A MAX
* Clock frequency : 100kHz MAX (1.8~5.5V)
400kHz MAX (2.5~5.5V)
* Write cycle time : 5ms MAX
* Address auto-increment function during read operation
* Automatic erase-before-write function during write operation
* Page write function : 32byte
* Inadvertent write protection function
Inadvertent write protection at low voltage (Vcc Lock-out function)
WP (Write Protect) function
* Schmitt trigger circuit and noise filter are built into SCL and SDA pins
* 1,000,000 write cycle typical
* 40 years data retention
* Operating temperature range : -40~85
BR24L32-FV Connection Diagram
