BR93L86RFJ-W

The features of BR93L86RFJ-W are: (1)microwire BUS EEPROM; (2)wide operating supply voltage range(2.5V to 5.5V); (3)1,000,000 erase/write cycles endurance.

The following is about the absolute maximum ratings of BR93L86RFJ-W: (1)supply voltage: -0.3 to 6.5V; (2)power dissipation: 450mW; (3)storage temperature: -65 to 125; (4)operating temperature: -40 to 85; (5)terminal voltage: -0.3 to VCC+0.3V.

The electrical characteristics of the BR93L86RFJ-W are: (1)"L" input voltage1: -0.3V min and 0.8V max; (2)"L" input voltage2: -0.3V min and 0.2xVCC max; (3)"H" input voltage1: 2.0V min and VCC+0.3V max; (4)"H" input voltage2: 0.7xVCC min and VCC+0.3V max; (5)"L" output voltage1: 0V min and 0.4V max at IOL=2.1mA, 4.0VCC5.5; (6)"L" output voltage2: 0V min and 0.2V max at IOL=100A, 2.5VCC4.0; (7)"H" output voltage1: 2.4V min and VCC max at IOL=0.4mA, 4.0VCC5.5; (8)"H" output voltage2: VCC-0.2V min and VCC max at IOL=100A, 1.8VCC4.0; (9)input leakage current: -1A min and 1A max.
