MFG:SIEMENS Package Cooled:TO-

Five Points

MFG: SIEMENS

Package Cooled: TO-

RATING	SYMBOL	VALUE	UNIT
Collector-emitter voltage(I_B=0)	V_CEO	400	V
Collector-emitter voltage(V_BE=0)	V_CES	1500	V
Emitter-base voltage(I_C=0)	V_EBO	11	V
Continuous vollector current	I_C	2	A
Peak collector current (see Note 1)	I_CM	2.5	A
Continuous base current	I_B	2	A
Peak base current (see Note 1)	I_BM	2.5	A
Continuous device dissipation at (or below) 25 case temperature	P_tot	50	W
Operating junction temperature range	T_j	-55 to +125
Storage temperature range	T_stg	-55 to +150
Lead temperature 3.2mm from case for 10 seconds	T_L	300

Designed for Self Oscillating Inverter
Applications
Rugged 1500 V Planar Construction
Integral Free-Wheeling Anti-Parallel Diode

BUPD1520
PDF/DataSheet Download
