CFPA10MD

Features: · Glass passivated cavity·free junction· Ideal for surface mount automotive application· Plastic package has Underwriters Lab. flammability classification 94V·0· Built·in strain relief· High temperature soldering guaranteed: 350 degree C/10sec, at terminals· For use in high frequency rec...

product image

CFPA10MD Picture
See larger image
SeekIC No. : 004313116 Detail

CFPA10MD: Features: · Glass passivated cavity·free junction· Ideal for surface mount automotive application· Plastic package has Underwriters Lab. flammability classification 94V·0· Built·in strain relief· Hi...

CFPA10MD Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
CFPA10MD
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/26

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

· Glass passivated cavity·free junction
· Ideal for surface mount automotive application
· Plastic package has Underwriters Lab. flammability classification 94V·0
· Built·in strain relief
· High temperature soldering guaranteed: 350 degree C/10sec, at terminals
· For use in high frequency rectifier circuits


Specifications

  SYMBOLS CFPA10MD UNITS
Maximum non repetitive peak reverse voltage VRSM 1200 Volts
Maximum repetitive peak reverse voltage VDC 1200 Volts
Maximum RMS voltage VRMS 840 Volts
Peak forward surge current 10ms single half sine-wave
superimposed on rated load		 IFSM 50 Amps
Maximum instantaneous forward voltage at 2.5A VF 1.0 Volts
Working peak forward current at TA=75°C IFWM 1.8 Amps
Peak repetitive forward surge current at TA=75°C IFRM 300 Amps
Maximum peak reverse current TA=25°C
at rated peak reverse voltage TJ=140°C		 IR 5
50		 mA
Maximum reverse recovery time (NOTE 1) trr 20.0 s
Maximum forward recovery time (NOTE 2) tfr 1.0 s
Typical junction capacitance (NOTE 2) CJ 40.0
 pF
Typical thermal resistance (NOTE 4) RJA 65 °C/W
Operating junction temperature range
 TJ -55 to +175 °C
Storage temperature range TSTG -55 to +175 °C
