CMP-5247TF-K

Series: -
Manufacturer: CUI Inc
Type: Electret Condenser
Output Type: Analog
Impedance: 2.2 kOhm
Current - Supply: 500µA
Port Location: Top
Seal Rating: None
Size / Dimension: 9.70mm Dia
Shape: Circular
Packaging: Bulk
Frequency Range: 100Hz ~ 20kHz
S/N Ratio: 58dB
Voltage - Rated: 1.5 ~ 10V
Termination: Solder Pads
Sensitivity: -47dB ±3dB
Height (Max): 5.40mm
Direction: Noise Cancelling


Specifications

directivity: noise cancelling

sensitivity: -47 dB ± 3 dB

sensitivity reduction: -3 dB

operating voltage: 1.5 Vdc

output impedance: 680 Ω

operating frequency: 100 ~ 20,000 Hz

current consumption: 0.5 mA

signal to noise ratio: 58 dBA

operating temperature: -20 ~ +70° C

storage temperature: -20 ~ +70° C

dimensions: ?9.7 x 5.2 mm

weight: 0.75 g

material: Al

termination: terminal type

640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram">

Parameters:

Technical/Catalog Information	CMP-5247TF-K
Vendor	CUI Inc
Category	Audio Products
Sensitivity	-47dB ±3dB
Voltage - Rated	1.5 ~ 10V
Current	500A
Type	Electret Condenser
Size / Dimension	Circular - 9.7mm Dia x 5.2mm H
Frequency	100Hz ~ 20kHz
S/N Ratio	58dB
Filter Type	-
Impedance	680 Ohm
Termination	Solder Pads
Direction	Noise Cancelling
Port Location	Top
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	CMP 5247TF K CMP5247TFK 102 1729 ND 1021729ND 102-1729
