COP688FH

Note 1: Absolute maximum ratings indicate limits beyond which damage to the device may occur. DC and AC electrical specifications are not ensured when operating the device at absolute maximum ratings.

The COP888FH Family of ROM based microcontrollers are highly integrated COP8™ Feature core devices with 12k memory and advanced features including Analog comparators, and Hardware Multiply/Divide. These single-chip CMOS devices are suited for more complex applications requiring a full featured controller, low EMI, two comparators, a full-duplex USART, and hardware multiply/divide functions. COP87L88FH devices are pin and software compatible (different V_CC range) 16k OTP (One Time Programmable) versions for pre-production , and for use with a range of COP8 software and hardware development tools. COP888FH Family features include an 8-bit memory mapped architecture, 10 MHz CKI with 1µs instruction cycle, hardware multiply/divide functions, three multi-function 16-bit timer/ counters with PWM, full duplex USART, MICROWIRE/ PLUS™, two Analog comparators, two power saving HALT/ IDLE modes, MIWU, idle timer, high current outputs, software selectable options WATCHDOG™ and clock/ oscillator mode, low EMI 2.5V to 5.5V operation, and 28/ 40/44 pin packages.

Devices included in this data sheet are:
