CST-911AP

Driver Circuitry: Transducer, Externally Driven
Input Type: zero-peak Signal
Operating Mode: Continuous
Washable: No
Mounting Type: Through Hole
Termination: PC Pins
Packaging: Tray
Manufacturer: CUI Inc
Technology: Magnetic
Voltage - Rated: 1.5Vo-p
Voltage Range: 1 ~ 2V
Frequency: 2.73kHz
Sound Pressure Level: 85dB @ 1.5V, 10cm
Current - Supply: 80mA
Series: CST
Size / Dimension: Circular - 9.00mm Dia x 5.00mm H


Specifications

recommended circuits: click here

rated voltage: 1.5Vo-p

operating voltage: 1.0-2.0Vo-p

mean current: 80mA Max

coil resistance: 6.0Ω ±1

sound pressure level: 85dB Min

rated frequency: 2730 Hz

operating temperature: -20 to +60°C

storage temperature: -30 to +70°C

diameter: 9.0 mm

depth: 4.5 mm

weight: 0.6 grams

640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram">

Parameters:

Technical/Catalog Information	CST-911AP
Vendor	CUI Inc
Category	Audio Products
Type	Magnetic Transducer, External Drive
Sound Pressure Level	85dB
Mounting Type	Through Hole
Capacitance @ Frequency	-
Frequency	2.73kHz
Packaging	Tray
Operating Mode	Continuous
Voltage Range	1~2Vo-p
Voltage - Rated	1.5Vo-p
Current Rating	80mA
Size / Dimension	Circular - 9mm Dia x 4.5mm H
Termination	Solder Pins/Posts
Capacitance	*
Adjustment Type	*
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	CST 911AP CST911AP 102 1457 ND 1021457ND 102-1457
