MFG:SONY Package Cooled:QFP D/C:03+
MFG: SONY
Package Cooled: QFP
D/C: 03+
Description: The CXD3511Q incorporates digital signal processor type RGB driver, color shading correction, selectab...
The CXD3511Q incorporates digital signal processor type RGB driver, color shading correction, selectable delay line and timing generator functions onto a single IC. Operation is possible with a system clock up to 200 [MHz] (max.). This IC can process video signals in bands up to UXGA standard, and can output the timing signals for driving various Sony LCD panels such as SXGA and XGA.
| Supply voltage | VDD 1 | VSS 0.5 to +3.0 | V |
| VDD2 | VSS 0.5 to +4.0 | V | |
| Input voltage | VI | VSS 0.5 to VDD1 + 0.5 | V |
| Output voltage | VO | VSS 0.5 to VDD1 + 0.5 | V |
| Storage temperature | Tstg | 55 to +150 | °C |
| Junction temperature | Tj | 125 | °C |
CXD3511Q
PDF/DataSheet Download
