Purchase CY7B9930V, In-stock CY7B9930V From SeekIC.
MFG:CYPRESS D/C:08+


Part Number: CY7B9930V
MFG: CYPRESS
D/C: 08+
Description: The CY7B9930V and CY7B9940V High-Speed Multi- Frequency PLL Clock Buffers offer user-selectable contro...
MFG:CYPRESS D/C:08+


MFG: CYPRESS
D/C: 08+
Description: The CY7B9930V and CY7B9940V High-Speed Multi- Frequency PLL Clock Buffers offer user-selectable contro...
The CY7B9930V and CY7B9940V High-Speed Multi- Frequency PLL Clock Buffers offer user-selectable control over system clock functions. This multiple-output clock driver provides the system integrator with functions necessary to optimize the timing of high-performance computer or communication systems.
Ten configurable outputs can each drive terminated transmission lines with impedances as low as 50 while delivering minimal and specified output skews at LVTTL levels. The outputs are arranged in three banks. The FB feedback bank consists of two outputs, which allows divide-by functionality from 1 to 12. Any one of these ten outputs can be connected to the feedback input as well as driving other inputs.
Selectable reference input is a fault tolerance feature that allows smooth change over to secondary clock source, when the primary clock source is not in operation. The reference inputs are configurable to accommodate both LVTTL or Differential (LVPECL) inputs. The completely integrated PLL reduces jitter and simplifies board layout.
CY7B9930V
PDF/DataSheet Download
