CY7C1382CV25 General Description
The Cypress Synchronous Burst SRAM family employs high speed, low-power CMOS designs using advanced single-layer polysilicon, triple-layer metal technology. Each memory cell consists of six transistors.
CY7C1382CV25 Maximum Ratings
(Above which the useful life may be impaired. For user guide-
lines, not tested.)
Storage Temperature .................................55°C to +1500C
Ambient Temperature with
Power Applied.............................................55°Cto +125°C
Supply Voltage on VDD
Relative to GND.................................................0.3V to +3.6V
DC Voltage Applied to Outputs
in High Z State[11]..................................0.5V to VDDQ + 0.5V
DC Input Voltage[11]..............................0.5V to VDDQ + 0.5V
Current into Outputs (LOW).............................................20 mA
CY7C1382CV25 Features
•Fast clock speed: 250, 225, 200, 167 MHz
•Provide high-performance 3-1-1-1 access rate
•Fast OE access times: 2.6, 2.8, 3.0, 3.4 ns
•Optimal for depth expansion
•Single 2.5V ±5% power supply
•Common data inputs and data outputs
•Byte Write Enable and Global Write control
•Chip enable for address pipeline
•Address, data, and control registers
•Internally self-timed Write cycle
•Burst control pins (interleaved or linear burst sequence)
•Automatic power-down available using ZZ mode or CE deselect
•Available in 119-ball bump BGA, 165-ball FBGA and 100-pin TQFP packages
•JTAG boundary scan for BGA packaging version
CY7C1382CV25 Connection Diagram
