SeekIC No. : 00175751 Detail

DH2x61-18A: Rectifiers 120 Amps 1800V

DH2x61-18A Data Sheet

Get Latest Price

Part Number:: DH2x61-18A
Mfg:: Ixys
Supply Ability:: 5000

Price Break

Qty
1~5000

Unit Price
Negotiable

Processing time
15 Days

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2025/12/23

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Product Details

Quick Details

Product :	Fast Recovery Rectifiers	Configuration :	Dual Parallel
Reverse Voltage :	1800 V	Forward Voltage Drop :	2.63 V
Recovery Time :	350 ns	Forward Continuous Current :	60 A
Max Surge Current :	650 A	Reverse Current IR :	200 uA
Mounting Style :	SMD/SMT	Package / Case :	SOT-227B
Packaging :	Tube

Description

Mounting Style : SMD/SMT
Product : Fast Recovery Rectifiers
Packaging : Tube
Reverse Current IR : 200 uA
Forward Continuous Current : 60 A
Configuration : Dual Parallel
Max Surge Current : 650 A
Reverse Voltage : 1800 V
Package / Case : SOT-227B
Forward Voltage Drop : 2.63 V
Recovery Time : 350 ns

Parameters:

Technical/Catalog Information	DH2X61-18A
Vendor	IXYS
Category	Discrete Semiconductor Products
Diode Type	Standard
Diode Configuration	2 Independent
Voltage - DC Reverse (Vr) (Max)	1800V (1.8kV)
Current - Average Rectified (Io) (per Diode)	60A
Voltage - Forward (Vf) (Max) @ If	2.63V @ 60A
Current - Reverse Leakage @ Vr	200A @ 1800V
Reverse Recovery Time (trr)	350ns
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Mounting Type	Chassis Mount
Package / Case	SOT-227B miniBLOC
Packaging	Tube
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	DH2X61 18A DH2X6118A
