Features: Extremely low collector-to-emitter saturation voltage( V CE(SAT) = 0.1V Typ. @IC /I B=100mA/10mA)Suitable for low voltage large current driversComplementary pair with DP030USwitching ApplicationPinoutSpecifications Characteristic Symbol Ratings Unit Collector-Base vo...
DN030U: Features: Extremely low collector-to-emitter saturation voltage( V CE(SAT) = 0.1V Typ. @IC /I B=100mA/10mA)Suitable for low voltage large current driversComplementary pair with DP030USwitching Appli...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Characteristic |
Symbol |
Ratings |
Unit |
Collector-Base voltage |
VCBO |
15 |
V |
Collector-Emitter voltage |
VCEO |
12 |
V |
Emitter-Base voltage |
VEBO |
5 |
V |
Collector current |
IC |
300 |
A |
Collector dissipation |
PC |
200 |
W |
Junction temperature |
Tj |
150 |
|
Storage temperature |
Tstg |
-55~150 |
