Part Number: DN8667NS



MFG: PAN

Package Cooled: 453

D/C: 02+



Urgent Purchase

DN8667NS Maximum Ratings

Parameter
Symbol
Rating
Unit
Supply voltage
VCC
0to+7.0
V
Output breakdown
VO
0 to+14
V
Output current
IO
150
mA
Power dissipation
PD
1.28
W
Operating ambient temperature
Topr
20 to +85
Storage temperature
Tstg
55 to +150

DN8667NS Features

* Serial-in, serial-out/parallel-out
* Cascade connection possible
* Constant current output (0 to 100 mA able to be set by one external resistor)
* Output-forced ON/OFF terminal attached (EN)
* Input/Output CMOS compatible

DN8667NS Typical Application

* LED panel drive

DN8667NS Connection Diagram

DN8667NS Connection Diagram
