Part Number: EMD40-900L



MFG: M/A-COM





Description: M/A-COM's EMD40-900L is a passive double balanced mixer in a low cost, surface mount SOIC-8 package. Fabricated using a m...


Urgent Purchase

EMD40-900L General Description


M/A-COM's EMD40-900L is a passive double balanced mixer in a low cost, surface mount SOIC-8 package. Fabricated using a mature silicon process (HMIC), it is ideally suited for high volume cellular and wireless applications. Typical applications include frequency up/down conversion, modulation and demodulation in GSM, AMPS, DAMPS and JDC frequencies.

EMD40-900L Maximum Ratings

Parameter
Absolute Maximum
RF Input Power
+17dBm
LO Drive Power
+17dBm
Operating/Storage Temp.
-40°C to +85°C

EMD40-900L Features

* SOIC-8 package
* IC process
* Low profile
* LO Drive +3dBm to +7dBm

EMD40-900L Connection Diagram

EMD40-900L Connection Diagram
