Ei16C554

The Ei16C554 is Universal Asynchronous Receiver and Transmitter with 16 byte transmit and receive FIFO. A programmable baud rate generator is provided to select transmit and receive clock rates from 50 Hz to 1.5MHz.

The Ei16C554 is an improved version of the Ei16C550 UART with higher operating speed and lower access time. The Ei16C554 on board status registers provides the error conditions, type and status of the transfer operation being performed. Included is complete MODEM control capability, and a processor interrupt system that may be software tailored to the user?s requirements. The Ei16C554 provides internal loopback capability for on board diagnostic testing.

The Ei16C554 is fabricated in an advanced CMOS process to achieve low drain power and high speed requirements.
