FDB088N08, US $ 1.09-1.69 , Fairchild Semiconductor, FDB088N08 DataSheet download, circuit diagram from SeekIC.com

See larger image

SeekIC No. : 00147749 Detail

FDB088N08: MOSFET NCH 75V 8.8Mohm

FDB088N08 Data Sheet

US $ 1.09~1.69 / Piece | Get Latest Price

Part Number:: FDB088N08
Mfg:: Fairchild Semiconductor
Supply Ability:: 5000

Price Break

Qty
0~1
1~25
25~100
100~250

Unit Price
$1.69
$1.37
$1.23
$1.09

Processing time
15 Days
15 Days
15 Days
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2025/12/4

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

FDB016N04AL7 evaluate
US $1.77 - 2.69 / Piece

MOSFET 40V N-Channel PowerTrench MOSFET
FDB024N04AL7 evaluate
US $1.66 - 2.52 / Piece

MOSFET 40V 2.4MOHM D2PAK-7L PowerTrench MOSFET
FDB024N06 evaluate
US $1.85 - 2.5 / Piece

MOSFET 60V N-Channel PowerTrench

Product Details

Quick Details

Transistor Polarity :	N-Channel	Drain-Source Breakdown Voltage :	75 V
Gate-Source Breakdown Voltage :	+/- 20 V	Continuous Drain Current :	85 A
Resistance Drain-Source RDS (on) :	7.3 mOhms	Configuration :	Single
Maximum Operating Temperature :	+ 175 C	Mounting Style :	SMD/SMT
Package / Case :	D2PAK	Packaging :	Reel

Description

Transistor Polarity : N-Channel
Gate-Source Breakdown Voltage : +/- 20 V
Configuration : Single
Maximum Operating Temperature : + 175 C
Mounting Style : SMD/SMT
Packaging : Reel
Package / Case : D2PAK
Drain-Source Breakdown Voltage : 75 V
Resistance Drain-Source RDS (on) : 7.3 mOhms
Continuous Drain Current : 85 A

Parameters:

Technical/Catalog Information	FDB088N08
Vendor	Fairchild Semiconductor (VA)
Category	Discrete Semiconductor Products
Mounting Type	Surface Mount
FET Polarity	N-Channel
Drain to Source Voltage (Vdss)	75V
Current - Continuous Drain (Id) @ 25° C	75A
Rds On (Max) @ Id, Vgs	8.8 mOhm @ 75A, 10V
Input Capacitance (Ciss) @ Vds	6595pF @ 25V
Power - Max	160W
Packaging	Digi-Reel?
Gate Charge (Qg) @ Vgs	118nC @ 10V
Package / Case	D²Pak, SMD-220, TO-263 (2 leads + tab)
FET Feature	Logic Level Gate
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	FDB088N08 FDB088N08 FDB088N08DKR ND FDB088N08DKRND FDB088N08DKR
