See larger image

SeekIC No. : 00146260 Detail

FDD8453LZ: MOSFET 40V N-Channel PowerTrench

FDD8453LZ Data Sheet

US $ .33~.48 / Piece | Get Latest Price

Part Number:: FDD8453LZ
Mfg:: Fairchild Semiconductor
Supply Ability:: 5000

Price Break

Qty
0~1
1~25
25~100
100~250

Unit Price
$.48
$.42
$.39
$.33

Processing time
15 Days
15 Days
15 Days
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2025/12/7

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

FDD8424H evaluate
US $.34 - .58 / Piece

MOSFET 40V Dual N & P-Ch PowerTrench MOSFET
FDD8424H_F085 evaluate
MOSFET PT2 P-Channel and PT4 N-channel
FDD8424H_F085A evaluate
US $.22 - .26 / Piece

MOSFET Dual N&PCH PwrTrench +/- 40V,20A

Product Details

Quick Details

Transistor Polarity :	N-Channel	Drain-Source Breakdown Voltage :	40 V
Gate-Source Breakdown Voltage :	+/- 20 V	Continuous Drain Current :	16.4 A
Resistance Drain-Source RDS (on) :	0.0067 Ohms	Configuration :	Single
Maximum Operating Temperature :	+ 150 C	Mounting Style :	SMD/SMT
Package / Case :	TO-252	Packaging :	Reel

Description

Transistor Polarity : N-Channel
Gate-Source Breakdown Voltage : +/- 20 V
Configuration : Single
Mounting Style : SMD/SMT
Packaging : Reel
Drain-Source Breakdown Voltage : 40 V
Maximum Operating Temperature : + 150 C
Package / Case : TO-252
Continuous Drain Current : 16.4 A
Resistance Drain-Source RDS (on) : 0.0067 Ohms

Parameters:

Technical/Catalog Information	FDD8453LZ
Vendor	Fairchild Semiconductor (VA)
Category	Discrete Semiconductor Products
Mounting Type	Surface Mount
FET Polarity	N-Channel
Drain to Source Voltage (Vdss)	40V
Current - Continuous Drain (Id) @ 25° C	16.4A
Rds On (Max) @ Id, Vgs	6.7 mOhm @ 15A, 10V
Input Capacitance (Ciss) @ Vds	3515pF @ 20V
Power - Max	3.1W
Packaging	Digi-Reel?
Gate Charge (Qg) @ Vgs	64nC @ 10V
Package / Case	DPak, SC-63, TO-252 (2 leads+tab)
FET Feature	Logic Level Gate
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	FDD8453LZ FDD8453LZ FDD8453LZDKR ND FDD8453LZDKRND FDD8453LZDKR
