FDW9926NZ

MOSFET 2.5V COMMON DRAIN NCH POWER TRENCH

product image

FDW9926NZ Picture
SeekIC No. : 00151922 Detail

FDW9926NZ: MOSFET 2.5V COMMON DRAIN NCH POWER TRENCH

floor Price/Ceiling Price

US $ .18~.35 / Piece | Get Latest Price
Part Number:
FDW9926NZ
Mfg:
Fairchild Semiconductor
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~25
  • 25~100
  • 100~250
  • Unit Price
  • $.35
  • $.3
  • $.22
  • $.18
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/3/27

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Transistor Polarity : N-Channel Drain-Source Breakdown Voltage : 20 V
Gate-Source Breakdown Voltage : +/- 12 V Continuous Drain Current : 4.5 A
Resistance Drain-Source RDS (on) : 27 m Ohms Configuration : Dual Common Dual Drain Dual Source
Maximum Operating Temperature : + 150 C Mounting Style : SMD/SMT
Package / Case : TSSOP-8 Packaging : Reel

Description

Transistor Polarity : N-Channel
Mounting Style : SMD/SMT
Packaging : Reel
Maximum Operating Temperature : + 150 C
Drain-Source Breakdown Voltage : 20 V
Gate-Source Breakdown Voltage : +/- 12 V
Continuous Drain Current : 4.5 A
Package / Case : TSSOP-8
Resistance Drain-Source RDS (on) : 27 m Ohms
Configuration : Dual Common Dual Drain Dual Source


Features:

4.5 A, 20 V. RDS(ON) = 32 m @ VGS = 4.5 V
                      RDS(ON) = 45 m@ VGS = 2.5 V
ESD protection diode (note 3)
High performance trench technology for extremely low RDS(ON) @ VGS = 2.5 V
Low profile TSSOP-8 package



Application

Battery protection
Load switch
Power management



Pinout

  Connection Diagram


Specifications

Symbol Parameter FDV302P Units
VDSS
Drain-Source Voltage 20 V
VGSS Gate-Source Voltage ±12 V
ID
Drain Current Continuous (Note 1a) Pulsed 4.5 A
30
PD Power Dissipation for Single Operation (Note 1a) (Note 1b) 1.6 W
1.1
TJ,TSTG
Operating and Storage Temperature Range 55 to +150 °C



Description

This N-Channel 2.5V specified MOSFET FDW9926NZ is a rugged gate version of Fairchild's Semiconductor's advanced PowerTrench process. FDW9926NZ has been optimized for power management applications with a wide range of gate drive voltage (2.5V 10V).


Parameters:

Technical/Catalog InformationFDW9926NZ
VendorFairchild Semiconductor
CategoryDiscrete Semiconductor Products
Mounting TypeSurface Mount
FET Polarity2 N-Channel (Dual)
Drain to Source Voltage (Vdss)20V
Current - Continuous Drain (Id) @ 25° C4.5A
Rds On (Max) @ Id, Vgs32 mOhm @ 4.5A, 4.5V
Input Capacitance (Ciss) @ Vds 600pF @ 10V
Power - Max1.1W
PackagingTape & Reel (TR)
Gate Charge (Qg) @ Vgs8nC @ 4.5V
Package / Case8-TSSOP
FET FeatureLogic Level Gate
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names FDW9926NZ
FDW9926NZ
