GU1086

Features: ·3-Terminal Adjustable or fixed 1.5V,1.8V,2.5V,3.3V,5.0V·1.4V Maximum Dropout at Full Load current·Fast Transient response·Built-in Thermal Shutdown·Output current limitingSpecifications Symbol Parameter Ratings Units Vin DC Supply Voltage -0.3 to 12 V PD Power Dissipat...

product image

GU1086 Picture
See larger image
SeekIC No. : 004357159 Detail

GU1086: Features: ·3-Terminal Adjustable or fixed 1.5V,1.8V,2.5V,3.3V,5.0V·1.4V Maximum Dropout at Full Load current·Fast Transient response·Built-in Thermal Shutdown·Output current limitingSpecifications ...

GU1086 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
GU1086
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/29

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

·3-Terminal Adjustable or fixed 1.5V,1.8V,2.5V,3.3V,5.0V
·1.4V Maximum Dropout at Full Load current
·Fast Transient response
·Built-in Thermal Shutdown
·Output current limiting


Specifications

Symbol Parameter Ratings Units
Vin DC Supply Voltage -0.3 to 12 V
PD Power Dissipation Internally Limited
TST Storage Temperature -65 ~ + 150
TOP Operating Junction Temperature Range 0 ~ + 150



Description

The GU1086 is a low dropout positive adjustable or fixed-mode regulator with minimum of 1.5A output current capability. The product is specifically designed to provide well-regulated supply for low voltage IC applications such as high-speed bus termination and low current 3.3V logic supply. GU1086 is also well suited for other applications such as VGA cards. GU1086 is guaranteed to have <1.4V dropout at full load current making it ideal to provide well-regulated outputs of 1.25 to 5.0V with 4.7 to 12V input supply by different output voltage.
