HHS60ZE-NT, US $ 77.68-77.68, HHS60ZE-NT DataSheet download, circuit diagram from SeekIC.com

See larger image

SeekIC No. : 003804080 Detail

HHS60ZE-NT: CONV DC-DC 48V IN 3.3V OUT 198W

HHS60ZE-NT Data Sheet

US $ 77.68~77.68 / Piece | Get Latest Price

Part Number:: HHS60ZE-NT
Mfg:
Supply Ability:: 5000

Price Break

Qty
0~1

Unit Price
$77.68

Processing time
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/5/4

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

HHS60 evaluate
Features: • Open-frame design with Insulated Metal Substrate• Low profile 12.7 mm hei...
HHS60ZD-NTS1 evaluate
DC/DC Converters
HHS60ZE-NT9 evaluate
US $80.45 - 80.45 / Piece

DC/DC Converters

Product Details

Quick Details

Series:	HHS	Manufacturer:	Power-One
Type:	Isolated	Number of Outputs:	1
Voltage - Input (Min):	36V	Voltage - Input (Max):	75V
Voltage - Output 1:	3.3V	Voltage - Output 2:	-
Voltage - Output 3:	-	Current - Output (Max):	60A
Power (Watts) - Manufacture Series:	198W	Voltage - Isolation:	1.5kV (1500V)
Features:	-	Mounting Type:	Through Hole
Package / Case:	9-DIP Module, 1/2 Brick	Size / Dimension:	2.40" L x 2.28" W x 0.50" H (61.0mm x 57.9mm x 12.7mm)
Package / Case :	TCSP-48	Packaging:	Tray
Operating Temperature:	-40°C ~ 110°C

Description

Type: Isolated
Number of Outputs: 1
Voltage - Output 2: -
Voltage - Output 3: -
Features: -
Voltage - Output 1: 3.3V
Mounting Type: Through Hole
Packaging: Tray
Efficiency: 90%
Voltage - Isolation: 1.5kV (1500V)
Voltage - Input (Min): 36V
Voltage - Input (Max): 75V
Size / Dimension: 2.40" L x 2.28" W x 0.50" H (61.0mm x 57.9mm x 12.7mm)
Package / Case: 9-DIP Module, 1/2 Brick
Manufacturer: Power-One
Current - Output (Max): 60A
Operating Temperature: -40°C ~ 110°C
Series: HHS
Power (Watts) - Manufacture Series: 198W

Parameters:

Technical/Catalog Information	HHS60ZE-NT
Vendor	Power-One
Category	Power Supplies
Voltage - Input	36 ~ 75VDC
Output	3.3V
Power (Watts)	198W
Number of Outputs	1
1st Output	3.3 VDC @ 60A
2nd Output	-
3rd Output	-
4th Output	-
Type	Isolated
Mounting Type	Through Hole
Packaging	Tray
Package / Case	9-DIP MODULE
Lead Free Status	Contains Lead
RoHS Status	RoHS Non-Compliant
Other Names	HHS60ZE NT HHS60ZENT 179 2245 ND 1792245ND 179-2245
