Part Number: HM5264805
Description: All inputs and outputs are reffered to the rising edge of the clock input. The HM5264165 Series, HM526...
- Table of contents:
HM5264805
-
Suppliers
DataSheet
General Description
HM5264805 General Description
All inputs and outputs are reffered to the rising edge of the clock input. The HM5264165 Series, HM5264805 Series, HM5264405 Series are offered in 4 banks for improved performance.
HM5264805 Maximum Ratings
| Parameter | Symbol | Value | Unit | Notes |
| Voltage on any pin relative to VSS | VT | 1.0 to +4.6 | V |
1
|
| Supply voltage relative to VSS | VCC | 1.0 to +4.6 | V | 1 |
| Short circuit output current | Iout | 50 | mA | |
| Power dissipation | PT | 1.0 | W | |
| Operating temperature | Topr | 0 to +70 | ||
| Storage temperature | Tstg | 55 to +125 |
Note: 1. Respect to VSS.
HM5264805 Features
· 3.3 V power supply
· Clock frequency: 100 MHz/83 MHz/66 MHz
· LVTTL interface
· Single pulsed RAS
· 4 banks can operate simultaneously and independently
· Burst read/write operation and burst read/single write operation capability
· Programmable burst length: 1/2/4/8/full page
· Programmable burst sequence
- Sequential/interleave
· Full page burst length capability
- Sequential burst
- Burst stop capability
· Programmable CAS latency: 2/3
· 4096 refresh cycles: 64 ms
· Clock frequency: 100 MHz/83 MHz/66 MHz
· LVTTL interface
· Single pulsed RAS
· 4 banks can operate simultaneously and independently
· Burst read/write operation and burst read/single write operation capability
· Programmable burst length: 1/2/4/8/full page
· Programmable burst sequence
- Sequential/interleave
· Full page burst length capability
- Sequential burst
- Burst stop capability
· Programmable CAS latency: 2/3
· 4096 refresh cycles: 64 ms
HM5264805 Connection Diagram
HM5264805F-75
PDF/DataSheet Download
- Datasheet: HM5264805F-75
- File Size: 891524 KB
- Manufacturer: HITACHI [Hitachi Semiconductor]
- Click here to Download
