Part Number: HM628512BI
Description: The Hitachi HM628512BI is a 4-Mbit static RAM organized 512-kword × 8-bit. HM628512BI Series has...
- Table of contents:
HM628512BI
-
Suppliers
DataSheet
General Description
HM628512BI General Description
The Hitachi HM628512BI is a 4-Mbit static RAM organized 512-kword × 8-bit. HM628512BI Series has realized higher density, higher performance and low power consumption by employing Hi-CMOS process technology. The HM628512BI Series offers low power standby power dissipation; therefore, it is suitable for battery backup systems. It has packaged in 32-pin SOP, 32-pin TSOP II and 32-pin DIP.
HM628512BI Maximum Ratings
| Parameter | Symbol | Value | Unit |
| Power supply voltage | VCC | 0.5 to +7.0 | V |
| Voltage on any pin relative to VSS | VT | 0.5* 1 to VCC + 0.3* 2 | V |
| Power dissipation | PT | 1.0 | W |
| Operating temperature | Topr | 40 to +85 | |
| Storage temperature | Tstg | 55 to +125 | |
| Storage temperature under bias | Tbias | 40 to +85 |
2. Maximum voltage is 7.0 V
HM628512BI Features
• Single 5 V supply
• Access time: 70/85 ns (max)
• Power dissipation
Active: 50 mW/MHz (typ)
Standby: 10 µW (typ)
• Completely static memory. No clock or timing strobe required
• Equal access and cycle times
• Common data input and output: Three state output
• Directly TTL compatible: All inputs and outputs
• Battery backup operation
• Operating temperature: 40 to +85˚C
• Access time: 70/85 ns (max)
• Power dissipation
Active: 50 mW/MHz (typ)
Standby: 10 µW (typ)
• Completely static memory. No clock or timing strobe required
• Equal access and cycle times
• Common data input and output: Three state output
• Directly TTL compatible: All inputs and outputs
• Battery backup operation
• Operating temperature: 40 to +85˚C
HM628512BI Connection Diagram
