General Description
HM62W9127H General Description
The HM62W8127H/HM62W9127H is an asynchronous 3.3 V operation high speed static RAM organized as 131,072-word×8/9-bit. It realize high speed access time (30/35/45 ns) with employing 0.8 mm CMOS process and high speed circuit designing technology. It is most appropriate for the application which requires high speed, high density memory and wide bit width configuration, such as cache and buffer memory in system. The HM62W8127H/HM62W9127H is packaged in 400-mil 32/36-pin SOJ for high density surface mounting.
HM62W9127H Maximum Ratings
| Parameter |
Symbol |
Value |
Unit |
| Supply voltage relative to VSS |
VCC |
0.5 to +4.6 |
V |
| Voltage on any pin relative to VSS |
VT |
0.5*1 to VCC+0.5 |
V |
| Power dissipation |
PT |
1.0 |
W |
| Operating temperatue range |
Topr |
0 to +70 |
°C |
| Storage temperature |
Tstg |
55 to +125 |
°C |
| Storage temperature under bias |
Tbias |
10 to + 85 |
°C |
Notes: 2.5 V for pulse width (under shoot) 10 ns
HM62W9127H Features
` Single 3.3 V supply: 3.3 V ± 0.3 V
` Access time 30/35/45 ns (max)
` Completely static memory
- No clock or timing strobe required
` Equal access and cycle times
` Directly CMOS compatible
- All inputs and outputs
` 400-mil 32/36-pin SOJ package
` Center VCC and VSS type pinout
` Access time 30/35/45 ns (max)
` Completely static memory
- No clock or timing strobe required
` Equal access and cycle times
` Directly CMOS compatible
- All inputs and outputs
` 400-mil 32/36-pin SOJ package
` Center VCC and VSS type pinout
HM62W9127H Connection Diagram
