HMC141C8

The HMC141C8 is a miniature passive doublebalanced mixer in a non-hermetic ceramic surface mount package that can be used as an upconverter or downconverter. The HMC141C8 is a passive diode/balun type mixer with high dynamic range. The mixer can handle larger signal levels than most active mixers due to the high third order intercept of 20 dBm. MMIC implementation provides exceptional balance in the circuit resulting in high LO/RF and LO/IF isolations and unitto- unit consistency. This mixer has applications where small size and surface mount compatibility are important.
