HSP-EVAL

Packaging:
Current - Supply (Main IC):
Frequency - Switching:
Voltage - Supply, Single/Dual (±):
Board Type:
Power (Typ) @ Conditions:
Voltage - Input:
Operating Temperature:
Regulator Topology:
Supplied Contents:
Series: -
Accessory Type: -
Channels per IC: -
Convert From (Adapter End): -
Main Purpose: -
Module/Board Type: -
Number of ADC's: -
Number of DAC's: -
Sensor Type: -
Amplifier Type: -
Applications: -
Convert To (Adapter End): -
Embedded: -
Number of Bits: -
Outputs and Type: -
Sensing Range: -
Interface: -
Max Output Power x Channels @ Load: -
Mounting Type: -
Output Type: -
Power - Output: -
Sampling Rate (Per Second): -
Utilized IC / Part: -
Data Interface: -
Features: -
Package / Case: -
Primary Attributes: -
Sensitivity: -
Slew Rate: -
Voltage - Output: -
Voltage - Supply: -
-3db Bandwidth: -
Current - Output: -
Input Range: -
Regulator Type: -
Settling Time: -
Supplier Device Package: -
Current - Output / Channel: -
DAC Type: -
Contents: Fully Assembled Evaluation Board
Type: DSP
Manufacturer: Intersil
For Use With/Related Products: HSPxx Family


Features:

• Single HSP-EVAL May be Used to Evaluate a Variety of Parts Within the HSPXXXXX Family of DSP Products
• May be Daisy Chained to Support Evaluation of Multi-Chip Solutions
• Parallel Port Interface to Support IBM PC™ Based Evaluation and Control
• Three Clocking Modes for Flexibility in Performance Analysis and Prototyping
• Dual 96-Pin Input/Output Connectors Conforming to the VME J2/P2 Connector Standard


Application

• PC Based Performance Analysis of HSPXXXXX Family of DSP Products
• Rapid Prototyping


Description

The HSP-EVAL is the mother board for a set of daughter boards based on the HSPxxxxx family of Digital Signal Processing products. Each product specific daughter board is mated with it to provide a mechanism for rapid evaluation and prototyping. As shown in Figure 1, the HSP-EVAL consists of a series of busses which provide input, output, and control to the target daughter board. These busses are brought out through dual 96 Pin connectors to support daisy chaining it for multichip prototyping and evaluation.

For added flexibility, the input and control busses can be driven by registers on-board the HSP-EVAL which have been down loaded with data via the parallel port of an IBM PCTM or compatible. In addition, a Shift Register is provided to serialize data on the daughter board output busses for reading into the PC via the status lines of the parallel port.

Together, the I/O and Control Registers can be used to drive the target daughter board with a PC based vector set while collecting daughter board outputs to the PC's disk.

Jumper selectable clock sources provide three different  methods of clocking the part under evaluation. In mode one, the clock signal is generated under PC based software control. In mode two, the HSP-EVAL's on-board oscillator may be selected as the clock source. In mode three, the user may provide an external clock through the 96 Pin Input Connector.

The HSP-EVAL was built into a 3U Euro-Card form factor with dual 96 Pin Input/Output connectors. The I/O connectors conform to the VME J2/P2 connector standard.

Parameters:

Technical/Catalog Information	HSP-EVAL
Vendor	Intersil
Category	Programmers, Development Systems
Type	DSP
Contents	Fully Assembled Evaluation Board
For Use With/Related Products	HSPxx Family
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	HSP EVAL HSPEVAL
