Features: ` Single 5V power supply` Low power consumption Operating: 400mW (Typ.) Standby: 5mW (Typ.)` 70ns (Max.) high speed access time` Power down by pin CS` TTL compatible interface levels` Fully static operation` Memory expansion by pin OE` Common I/O using tri-state outputs` Pin-compatible w...
HT6116-70: Features: ` Single 5V power supply` Low power consumption Operating: 400mW (Typ.) Standby: 5mW (Typ.)` 70ns (Max.) high speed access time` Power down by pin CS` TTL compatible interface levels` Full...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Supply Voltage ...........................0.3V to +7.0V
Input Voltage................. VSS0.3V to VDD+0.3V
Storage Temperature............50°C to +125°C
Operating Temperature...........40°C to +85°C
*Note: Stresses above those listed under "Absolute Maximum Ratings" may cause permanent damage to the device. These are stress ratings only. Functional operation of this device at these or any other conditions above those indicated in the operational sections of this specification is not implied and exposure to absolute maximum rating conditions for extended periods may affect device reliability.
The HT6116-70 is a 16384-bit static random access memory. It is organized with 2048 words of 8 bits in length, and operates with a single 5V power supply. The IC is built with a high performance CMOS 0.8mm process in order to obtain a low standby current and high reliability. The IC contains six-transistor full CMOS memory cells and TTL compatible inputs and outputs, which are easily interface with common system bus structures. The Data bus of the HT6116-70 is designed as a tri-state type. The IC is in the standby mode if the CS pin is set to "high".
