HYM368020S-60

The HYM HYM368020S-60  is a 32 MByte DRAM module organized as 8 388 608 words by 36-Bit in a 72-pin single-in-line package comprising sixteen HYB 5117400BJ 4M ´ 4 DRAMs and eight HYB 514100BJ 4M x 1 DRAMs in 300 mil wide SOJ-packages mounted together with 24 0.2 F ceramic decoupling capacitors on a PC board.

The HYM HYM368020S-60 can also be used as a 16 777 360 words by 18-bits dynamic RAM module by means of connecting DQ0 and DQ18, DQ1 and DQ19, DQ2 and DQ20, . , DQ17 and DQ35, respectively.

Each HYB HYM368020S-60 is described in the data sheet and is fully electrical tested and processed according to SIEMENS standard quality procedure prior to module assembly. After assembly onto the board, a further set of electrical tests is performed.

The speed of the HYM368020S-60 module can be detected by the use of four presence detect pins.

The common I/O feature on the HYM368020S-60 dictates the use of early write cycles.
