Features: `80C51 based architecture`4K x 8 ROM (IC80LV51 only)`128 x 8 RAM`Two 16-bit Timer/Counters`Full duplex serial channel`Boolean processor`Four 8-bit I/O ports, 32 I/O lines`Memory addressing capability-64K ROM and 64K RAM`Programmable lock-Lock bits (2)`Power save modes:-Idle and power-dow...
IC80LV31: Features: `80C51 based architecture`4K x 8 ROM (IC80LV51 only)`128 x 8 RAM`Two 16-bit Timer/Counters`Full duplex serial channel`Boolean processor`Four 8-bit I/O ports, 32 I/O lines`Memory addressing...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Symbol |
Parameter |
Value |
Unit |
VTERM | Terminal Voltage with Respect to GND(2) |
-2.0 to +7.0 |
V |
TBIAS | Temperature Under Bias(3) |
0 to +70 |
|
TSTG | Storage Temperature |
-65 to +125 |
|
PT | Power Dissipation |
1.5 |
W |
Note:
1.Stress greater than those listed under ABSOLUTE MAXIMUM RATINGS may cause permanent damage to the device. This is a stress rating only and functional operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect reliability.
2.Minimum DC input voltage is C0.5V. During transitions, inputs may undershoot to C2.for periods less than 20 ns. Maximum DC voltage on output pins is Vcc + 0.5V which may overshoot to Vcc + 2.0V for periods less than 20 ns.
3.Operating temperature is for commercial products only defined by this specification.
The IC80LV31 are high-performance microcontrollers fabricated using high-density CMOS technology. The CMOS IC80LV51/31 is functionally compatible with the industry standard 80C51 micro-controllers.
The IC80LV31 is designed with 4K x 8 ROM (IC80LV51 only); 128 x 8 RAM; 32 programmable I/O lines; a serial I/O port for either multiprocessor communications, I/O expansion or full duplex UART; two 16-bit timer/counters ; a six-source, two-priority-level, nested interrupt structure ; and an on-chip oscillator and clock circuit. The IC80LV31 can be expanded using standard TTL compatible memory.
