Part Number: ICS843207-350
Description: The ICS843207-350 is a low phase-noise frequency margining synthesizer that targets clocking for high ...
- Table of contents:
ICS843207-350
-
Suppliers
DataSheet
General Description
ICS843207-350 General Description
The ICS843207-350 is a low phase-noise frequency margining synthesizer that targets clocking for high performance interfaces such as SPI4.2 and is a member of the HiPerClockS™ family of high performance clock solutions from IDT. In the default mode, each output can be configured individually to generate an 87.5MHz, 175MHZ or 350MHz LVPECL output clock signal from a 14MHz crystal input. There is also a frequency margining mode available where the device can be configured, using control pins, to vary the output frequency up or down from nominal by 5%. The ICS843207-350 is provided in a 48-pin LQFP package.
ICS843207-350 Maximum Ratings
Supply Voltage, VCC 4.6V
Inputs, VI -0.5V to VCC + 0.5V
Outputs, IO
Continuous Current 50mA
Surge Current 100mA
Package Thermal Impedance, JA 65.7°C/W (0 mps)
Storage Temperature, TSTG -65°C to 150°C
NOTE: Stresses beyond those listed under Absolute Maximum Ratings may cause permanent damage to the device. These ratings are stress specifications only. Functional operation of product at these conditions or any conditions beyond those listed in the DC Characteristics or AC Characteristics is not implied. Exposure to absolute maximum rating conditions for extended periods may affect product reliability.
Inputs, VI -0.5V to VCC + 0.5V
Outputs, IO
Continuous Current 50mA
Surge Current 100mA
Package Thermal Impedance, JA 65.7°C/W (0 mps)
Storage Temperature, TSTG -65°C to 150°C
NOTE: Stresses beyond those listed under Absolute Maximum Ratings may cause permanent damage to the device. These ratings are stress specifications only. Functional operation of product at these conditions or any conditions beyond those listed in the DC Characteristics or AC Characteristics is not implied. Exposure to absolute maximum rating conditions for extended periods may affect product reliability.
ICS843207-350 Features
• Seven independently configurable LVPECL outputs at 87.5MHz, 175MHz or 350MHz
• Individual high impedance control of each output
• Selectable crystal oscillator interface designed for 14MHz, 18pF parallel resonant crystal or LVCMOS single-ended input
• Output frequency can be varied ± 5% from nominal
• VCO range: 620MHz - 750MHz
• Full 3.3V supply mode
• 0°C to 70°C ambient operating temperature
• Available in both standard (RoHS 5) and lead-free (RoHS 6) packages
• Individual high impedance control of each output
• Selectable crystal oscillator interface designed for 14MHz, 18pF parallel resonant crystal or LVCMOS single-ended input
• Output frequency can be varied ± 5% from nominal
• VCO range: 620MHz - 750MHz
• Full 3.3V supply mode
• 0°C to 70°C ambient operating temperature
• Available in both standard (RoHS 5) and lead-free (RoHS 6) packages
ICS843207-350 Connection Diagram
