Purchase IDP30E120, In-stock IDP30E120 From SeekIC.
MFG:moseft Package Cooled:INFINEON D/C:07+
- Table of contents:
IDP30E120
-
Suppliers
DataSheet
General Description
IDP30E120 Maximum Ratings
| Parameter | Symbol | Value | Unit |
| Repetitive peak reverse voltage | VRRM | 1200 | V |
| Continous forward current TC=25°C TC=90°C |
IF | 50 30 |
A |
| Surge non repetitive forward current TC=25°C, tp=10 ms, sine halfwave |
IFSM | 102 | |
| Maximum repetitive forward current TC=25°C, tp limited by Tjmax, D=0.5 |
IFRM | 76.5 | |
| Power dissipation TC=25°C TC=90°C |
Ptot | 138 66 |
W |
| Operating and storage temperature | Tj , Tstg | -55...+150 | °C |
| Soldering temperature 1.6mm(0.063 in.) from case for 10s |
TS | 260 | °C |
IDP30E120 Features
·1200 V EmCon® technology
·Fast recovery
·Soft switching
·Low reverse recovery charge
·Low forward voltage
·Easy paralleling
·Fast recovery
·Soft switching
·Low reverse recovery charge
·Low forward voltage
·Easy paralleling
IDP30E120
PDF/DataSheet Download
- Datasheet: IDP30E120
- File Size: 216079 KB
- Manufacturer: INFINEON [Infineon Technologies AG]
- Click here to Download
