Part Number: IDT74AUC16374
Description: This 16-bit edge-triggered D-type flip-flop is built using advanced CMOS technology. The AUC16...


Description: This 16-bit edge-triggered D-type flip-flop is built using advanced CMOS technology. The AUC16...
This 16-bit edge-triggered D-type flip-flop is built using advanced CMOS technology.
The AUC16374 is particularly suitable for implementing buffer registers, I/O ports, bidirectional bus drivers, and working registers. It can be used as two 8-bit flip-flops or one 16-bit flip-flop. On the positive transition of the clock (CLK) input, the Q outputs of the flip-flop take on the logic levels at the data (D) inputs. OE can be used to place the eight outputs in either a normal logic state (high or low logic levels) or a high-impedance state. In the high-impedance state, the outputs neither load nor drive the bus lines significantly. The high-impedance state and the increased drive provide the capability to drive bus lines without need for interface or pullup components. OE does not affect the internal operation of the flip-flop.
Old data can be retained or new data can be entered while the outputs are in the high-impedance state. This device is fully specified for partial power-down applications using IOFF. The IOFF circuitry disables the outputs, preventing damaging current backflow through the device when it is powered down.
To ensure the high-impedance state during power up or power down, OE should be tied to VDD through a pull-up resistor; the minimum value of the resistor is determined by the current-sinking capability of the driver.
|
Description |
Symbol |
Max |
unit |
|
Terminal Voltage with Respect to GND |
VTERM(2) |
0.5 to +4.6
|
V |
|
Terminal Voltage with Respect to GND |
VTERM(3)
|
0.5 to VCC+0.5 |
V |
|
Storage Temperature |
TSTG |
65 to +150
|
° C |
|
DC Output Current |
IOUT
|
50 to +50 |
mA |
|
Continuous Clamp Current, VI < 0 or VI > VCC |
IIK |
±50
|
mA |
|
Continuous Clamp Current, VO < 0 |
IOK |
50 |
mA |
|
Continuous Current through each VCC or GND |
ICC ISS |
±100 |
mA |
