IDTQS32XR245

   The QS32XR245 is a member of the MultiWidth^TM  family of QuickSwitch devices and provides a set of 32 high-speed low resistance CMOS compatible bus switches in a flow-thru pinout. This device is available in the MillipaQ package, the world's first small outline 16-bit solution.  The low on-resistance of the QS32XR245 allows inputs to be connected to outputs without adding propagation delay and without generating additional ground bounce noise.  When Output Enable (OEn ) is low, the switches are turned on, connecting bus A to bus B.  When OEn is high, the switches are turned off. This device is ideally suited for 16/32 bit applications where board space is at a premium.The low resistance of QS32XR245 makes it ideal for PCI hot docking application.

  QuickSwitch devices provide an order of magnitude faster speed than conventional logic devices.

  The QS32XR245 is characterized for operation at -40°C to +85°C.
