Purchase IL54123, In-stock IL54123 From SeekIC.
Part Number: IL54123
Description: The IL54123N/D is designed for use in earth leakage circuit interrupters for operation directly off th...
- Table of contents:
IL54123
-
Suppliers
DataSheet
General Description
IL54123 General Description
The IL54123N/D is designed for use in earth leakage circuit interrupters for operation directly off the AC Line in breakers.
It contains pre regulator, main regulator, after regulator, differential amplifier, level comparator, latch circuit. The input in the differential amp latch circuit. The input in the differential amplifier is connect to the secondary node of zero current transformer.
The level comparator generates high level when earth leakage current is greater than some level.
IL54123 Maximum Ratings
Supply Voltage .........................................20V
Supply Current .........................................8mA
Power Dissipation ............................200m W
Operating Temperature ..............- 40 to 85
Storage Temperature ................ - 55 to 125
Supply Current .........................................8mA
Power Dissipation ............................200m W
Operating Temperature ..............- 40 to 85
Storage Temperature ................ - 55 to 125
IL54123 Features
• Low Power Consumption (PD=5mW) 100V/200V
• 100V/200V Common Built-in Voltage Regulator
• High Gain Differential Amplifier
• High Input Sensitivity (VT = 6.1mV Typ.)
• Minimum External Parts
• Large Surge Margin
• Wide Operating Temperature Range (T= -40 to 85)
• High Noise Immunity
• Meet U. L. 943 standards
• 100V/200V Common Built-in Voltage Regulator
• High Gain Differential Amplifier
• High Input Sensitivity (VT = 6.1mV Typ.)
• Minimum External Parts
• Large Surge Margin
• Wide Operating Temperature Range (T= -40 to 85)
• High Noise Immunity
• Meet U. L. 943 standards
IL54123 Connection Diagram
